Zebronics UPS Specifications

General

 * Capacity (VA/W): 600VA / 360W

Input

 * Nominal Voltage: 220-240 VAC

 * Voltage Range: 140-300 VAC

 * Frequency: 50/60 Hz

 * Plug Type: 3 Pin Plug

 * Input Protection: Internal Fuse

Output

 * Voltage Range (AC mode): 230VAC ± 10%

 * Voltage Range (Batt. Mode): 230VAC ± 10%

 * Frequency Range (Batt. Mode): 50/60Hz ± 1%

 * Transfer Time: 4-8ms

 * Waveform: Simulated Sine Wave

 * No. of Output Sockets: 3

 * Protections: Overload, Short Circuit, Over Discharge & Over Charge

Battery

 * Battery Type: 12V 7Ah x 1 Nos.

 * Charging Current: 1A

 * Recharge Time: 6-8h to Charge 90% (After Complete Discharge)

Indicators & Alarms

 * No. of LEDs: 3 LED

 * AC Mode: Green LED Glows

 * Battery Mode: Orange LED Blinks; Beeping Every 10 Seconds

 * Low Battery: Beeping Every 1 Second

 * Overload: Beeping Every 0.5 Second

 * Fault Mode: Red LED Glow; Continuous Beeping

Physical & Environmental

 * Dimension: 10.1 x 28 x 14.2 cm (W x D x H)

 * Net Weight: 3.82 kg

 * Package Dimension: 32.6 x 14.2 x 21.3 cm (W x D x H)

 * Operational Temperature: 0-40°C

 * Noise Level: <45dB
